» 77T(195 mesh) polyester silk screen printing mesh / bolting cloth

77T(195 mesh) polyester silk screen printing mesh / bolting cloth

The 77T-55 mesh is considered to be a fine mesh, which can provide delicate printing effects and is widely used for printing on textiles, graphics, PCBs, etc. With high tension and low elongation, excellent tear resistance and dimensional stability

Product Name: 77T-55 polyester silk screen printing mesh

Material: 100% polyester monofilament

Mesh Count/cm: 77T

Mesh Count/inch: 195 mesh/inch

Color: White, Yellow

Width: 127cm, 165cm or customized

Roll Length: 30-100m or customized

Thread Diameter:55 micron

Weave type: Plain weave

The difference of white and yellow color screen printing mesh?
White mesh is the more economical of the two, and is primarily seen in lower mesh counts used for less-detailed designs. Higher count mesh is usually dyed yellow because the color yellow acts as a canceling factor for UV light and prevents refraction along the mesh strands when burning your screens. This allows for a more focused and precise exposure, keeping your screens as crisp as possible.
