Product packaging and plastic containers come in a variety of forms, everywhere, in today’s packaging and plastics industries, where competition is fierce and competitive. Fast and smooth screen production, high-quality and reliable screen printing mesh, bring the most cost-effective production process. It is widely used in these industries to increase the value and advantages of its products and stand out among many products.

Material Polyester; Nylon; Stainless steel
Specification 36T -165T
Mesh count 80-420 mesh
Woven type Plain woven
Color White ; Yellow
Width 127cm,145cm,165cm,2.50cm etc,customize
Production type  Roll cloth
The length of roll 30-80m; Can be customized length; Customize

Advantage:

  • Wear-resistant;
  • Easy to clean;
  • Long life;
  • Good ink leakage;
  • The tensile strength is small and the dimensional stability is good;
  • Heat resistance and low hygroscopicity;
  • Mesh opening is uniform;
  • The standard of mesh count

Application:

  1. Carton;
  2. Carton;
  3. Bottle;
  4. School bag  etc;
  5. Aspect bags;
  6. Bags;
  7. CD;
  8. Credit card

    PACKAGING SCREEN PRINTING MESH

    Model Specification
    (cm)
    Mesh count
    (mesh/inch)
    Thread Diameter(um) Mesh opening(um) Open Area(%) Thickness(um) Theoretic Ink Volume
    (cm3/m2)
    Request a Quote
    PET36/169 36 90 100 169 39 170 66
    PET39/149 39 99 100 149 35 170 60
    PET43/145 43 110 80 145 41 136 56
    PET47/135 47 120 71 135 42 121 51
    PET53/112 53 135 71 112 37 121 45
    PET64/96 64 163 55 96 39 94 36
    PET64/88 64 163 64 88 33 109 35
    PET77/71 77 195 55 71 31 94 29
    PET100/51 100 254 40 51 30 85 26
    PET110/43 110 280 40 43 26 68 18
    PET120/44 120 305 31 44 33 53 18
    PET120/42 120 305 34 42 29 58 17
    PET120/37 120 305 40 37 18 68 13
    PET130/34 130 330 40 34 19 68 13
    PET140/34 140 350 31 34 25 53 13
    PET150/34 150 380 27 34 30 46 14
    PET165/31 165 420 27 31 24 46 11
