Screen Printing Mesh

The largest application market of economical screen printing mesh is the textile printing industry, where printing presses continue to exceed creative limits and are highly competitive.

Screen printing mesh is ideal for light or heavy textile fabric and garments screen printing. You should decide your needed mesh counts according to your substrates.The textiles printed by the economical screen printing mesh have bright colors and colorful patterns. At the same time, it is also possible to convert the interior printing materials of the apartment into a fashionable, high- quality and gorgeous.

Material Polyester; Nylon; Stainless steel
Specification 12T -120T
Mesh count 30-300 mesh
Woven type Plain woven
Color White; Yellow
Width 127cm,145cm,165cm,2.50cm etc,customize
Production type Roll cloth
The length of roll 30-80m; Can be customized length; Customize

Features

  • Wide product range for all screen printing requirements.
  • Efficient production and reproducible for both stencil preparation and screen printing process.
  • Low elongation and high accuracy make your screen printing beautiful, high grade and innovative.
  • Suitable for various screen printing machines and different printing inks.
  • Custom service for stencil makers and solar panel printers.
  • Reduce production costs and production loss for your glass printing.
  • Competitive prices help you occupy more markets in your local markets.

Contact Us

TAXTILE SCREEN PRINTING MESH

Model Specification
(/cm)
Mesh count
(mesh/inch)
Thread Diameter(um) Mesh opening(um) Open Area(%) Thickness(um) Theoretic Ink Volume
(cm3/m2)
Request a Quote
PET12/686 12 30 140 686 68 277 189
PET16/461 16 40 140 461 58 238 139
PET20/399 20 50 80 399 69 136 93
PET20/380 20 50 100 380 62 170 105
PET24/320 24 60 80 320 63 136 86
PET24/301 24 60 100 301 56 170 95
PET28/263 29 70 120 214 41 204 83
PET32/236 32 80 64 236 61 109 67
PET32/221 32 80 80 221 53 136 73
PET36/188 36 90 80 188 49 136 66
PET36/178 36 90 90 178 44 153 67
PET39/191 39 99 55 191 60 94 56
PET39/183 39 99 64 183 54 109 59
PET39/176 39 99 71 176 50 121 61
PET43/145 43 110 80 145 41 136 56
PET47/150 47 120 55 150 53 94 50
PET47/141 47 120 64 141 47 109 51
PET53/127 53 135 55 127 48 94 45
PET53/118 53 135 64 118 42 109 45
PET59/109 59 150 55 109 42 94 40
PET64/96 64 163 55 96 39 94 36
PET72/89 72 183 45 89 42 77 32
PET72/86 72 183 48 86 40 82 32
PET80/76 80 200 45 76 38 77 29
PET80/73 80 200 48 73 35 82 29
PET90/68 90 230 40 68 38 68 26
PET90/63 90 230 45 63 33 77 25
PET100/51 100 254 40 51 30 85 26
PET110/43 110 280 40 43 26 68 18
PET120/37 120 305 40 37 18 68 13
Remark:The above datas are theoretic ,please reference the actual datas if there it differs.

Delivery
For small testing ordre We will sending the goods within 1-3 days.For bigger order will send the goods within 7-10 days
