Polyester (PET) screen printing mesh is widely and popularly used in the glass industry. It supplies uniform, colorful and accurate printing for both decorative and functional applications.It is widely used for automotive glass, building decorative glass, household glass as well as different shapes and sized hollow glassware.
You can get polyester screen printing mesh as well as nylon screen printing mesh for screen printer or for stencil makers.

Material Polyester;  Nylon;  Stainless steel
Specification 36T -140T
Mesh count 90-420 mesh
Woven type Plain woven
Color White ; Yellow
Width 127cm,145cm,165cm,2.50cm etc,Customize
Production type  Roll cloth
The length of roll 30-80m,Can be customized length; Customize

Features

  • Wide ranges of mesh counts for all requirements and accuracy of screen printing.
  • Ideal for automobile glass, household appliance glass and various shaped bottles printing.
  • Maximum efficient and reproducible for glass screen printing production.
  • Suitable for various screen printing machines and different printing inks.
  • Custom service for stencil makers and solar panel printers.
  • Reduce production costs and production loss for your glass printing.
  • Competitive prices help you occupy more markets in your local markets.

Applications
✔Hollow ware glass screen printing
✔Home appliance glass screen printing
✔Construction glass screen printing
✔Automotive glass screen printing

    TAXTILE SCREEN PRINTING MESH

    Model Specification
    (cm)
    Mesh count
    (mesh/inch)
    Thread Diameter(um) Mesh opening(um) Open Area(%) Thickness(um) Theoretic Ink Volume
    (cm3/m2)
    Request a Quote
    PET36/169 36 90 100 169 39 170 66
    PET39/149 39 99 100 149 35 170 60
    PET43/145 43 110 80 145 41 136 56
    PET47/135 47 120 71 135 42 121 51
    PET53/112 53 135 71 112 37 121 45
    PET64/96 64 163 55 96 39 94 36
    PET64/88 64 163 64 88 33 109 35
    PET77/71 77 195 55 71 31 94 29
    PET100/51 100 254 40 51 30 85 26
    PET110/43 110 280 40 43 26 68 18
    PET120/44 120 305 31 44 33 53 18
    PET120/42 120 305 34 42 29 58 17
    PET120/37 120 305 40 37 18 68 13
    PET130/34 130 330 40 34 19 68 13
    PET140/34 140 350 31 34 25 53 13
    PET150/34 150 380 27 34 30 46 14
    PET165/31 165 420 27 31 24 46 11
