advertisement Screen Printing Mesh

Screen Printing Mesh

Screen printing mesh is ideal for print processing; Special prints; Posters; Transfer graphics; Pictures and decals; Providing ideal conditions for rendering high-contrast images.

Screen printing mesh is printed on the incredible surface of graphics and patterns. It can be printed on almost any material with different color coverage. The image has good weather resistance; and the possible color series can be determined according to the customer’s concept. Printed patterns with exquisite detail, bright colors with high durability and special surfaces, countless products reflect the wide application value and unique advantages of this printing process.

Material Polyester; Nylon; Stainless steel
Specification 12T -165T
Mesh count 18-420 mesh
Woven typeP lain woven
Color White; Yellow
Width 127cm,145cm,165cm,2.50cm etc,customize
Production type  Roll cloth
The length of roll 30-80m; Can be customized length; Customize

Advantage：

  • 1.Wear-resistant, easy to clean, long life;
  • 2.Good ink leakage;
  • 3.The tensile strength is small and the dimensional stability is good;
  • 4.Heat resistance and low hygroscopicity;
  • 5. Mesh opening is uniform, the standard of mesh count



  1. Label printing;
  2. Decorative stickers;
  3. Decals; Poster

Contact Us

ADVERTISEMENT SCREEN PRINTING MESH

Model Specification
(cm)		 Mesh count
(mesh/inch)		 Thread Diameter（um） Mesh opening（um） Open Area（%） Thickness（um） Theoretic Ink Volume
(cm3/m2)		 Request a Quote
PET12/686 12 30 140 686 68 277 189
PET16/461 16 40 140 461 58 238 139
PET20/380 20 50 100 380 62 170 105
PET24/301 24 60 100 301 56 170 95
PET28/263 28 70 80 263 58 136 79
PET28/244 28 70 100 244 50 170 85
PET32/221 32 80 80 221 53 136 73
PET36/178 36 90 90 178 44 153 67
PET39/183 39 99 64 183 54 109 59
PET39/176 39 99 71 176 50 121 61
PET43/145 43 110 80 145 41 136 56
PET47/141 47 120 64 141 47 109 51
PET53/118 53 135 64 118 42 109 45
PET59/109 59 150 55 109 42 94 40
PET61/103 61 155 55 103 41 94 38
PET64/96 64 163 55 96 39 94 36
PET68/87 68 173 55 87 36 94 34
PET72/86 72 183 48 86 40 82 32
PET80/73 80 200 48 73 35 82 29
PET90/63 90 230 45 63 33 77 25
PET100/51 100 254 40 51 30 85 26
PET110/43 110 280 40 43 26 68 18
PET120/37 120 305 40 37 18 68 13
PET130/31 130 330 40 31 17 68 12
PET140/32 140 350 34 32 19 58 11
PET150/31 150 380 30 31 23 51 12
PET165/25 165 420 31 25 16 53 8

Delivery
For small testing ordre We will sending the goods within 1-3 days.For bigger order will send the goods within 7-10 days
